Name: Seasonic Prime Fanless PX-500 500W Platinum PSU (SSR-500PL)
Brand: Seasonic
SKU: V28-PSUSEAPX500
Price: 509.40 AUD
Availability: InStock

Product Description

FEATURE SUMMARY

80 PLUS® Platinum certified

Micro Tolerance Load Regulation (0.5%)

True Fanless Design

Multi-GPU setup

Gold plated connectors

12 years warranty

Technical Specifications
80PLUS®		Platinum
Cybenetics Efficiency Level		TBA
Cybenetics Noise Level		TBA
Form Factor		Intel ATX 12V
Dimensions		140 mm (L) x 150 mm (W) x 86 mm (H)
Fan Information	Fan Size	N/A
	Fan Control	N/A
	Fan Bearing	N/A
	Life Expectancy	N/A
Cable Information	Modularity	Fully Modular
Cable Information	Cable type	Webbed cables (MB, CPU, PCIe) Flat black cables
Electrical Features	Operating Temperature	0 - 50°C (derating from 100% to 80% from 40°C to 50°C)
	MTBF @ 25 °C, excl. fan	150,000 hours
	AC Input	Full Range
	Protection	OPP, OVP, UVP, OCP, OTP, SCP
Safety and Environmental	Safety and EMC	cTUVus, TUV, CB, CCC, BSMI, EAC, CE
Safety and Environmental	Environmental Compliance	Energy Star, RoHS, WEEE, ErP Lot 6, REACH
Warranty		12 Years

Power Output
AC Input	Voltage: 100 V - 240 V
	Current: 7 - 4 A
	Frequency: 50 Hz - 60 Hz
DC Output	Rail	+3.3 V	+5 V	+12 V	-12 V	+5 VSB
	Maximum Power	20 A	20 A	41 A	0.3 A	3 A
	Maximum Power	100 W		492 W	3.6 W	15 W
	Total Continuous Power	500 W
